Alice Weekly Meeting: Software for Hardware Accelerators / PDP-SRC

Wednesday 3 Apr 2024, 11:00 → 12:20 Europe/Zurich

11:00 → 11:20 Discussion

Speakers: David Rohr (CERN), Ole Schmidt (CERN)

Color code: (critical, news during the meeting: green, news from this week: blue, news from last week: purple, no news: black)

High priority RC YETS issues:

• Fix dropping lifetime::timeframe for good: No news

  • Still pending: problem with CCDB objects getting lost by DPL leading to "Dropping lifetime::timeframe", saw at least one occation during SW validation.
• Start / Stop / Start:

  • Problems in readout and QC fixed. Now 2 new problems left:

    • Some processes are crashing randomly (usually ~2 out of >10k) when restarting. Stack trace hints to FMQ. https://its.cern.ch/jira/browse/O2-4639

    • TPC ITS matching QC crashing accessing CCDB objects. Not clear if same problem as above, or a problem in the task itself.

• Stabilize calibration / fix EoS: New scheme: https://its.cern.ch/jira/browse/O2-4308: No news

• Implemented the heuristic to reduce InfoLoggerMessages when hittung number of TFs in flight. To be checked at P2.
• Fix problem with ccdb-populator: no idea yet, no ETA.
• Run 548532 crashed with internal-dpl-ccdb-backend PSS size going to > 60 GB causing OOM.

  • Improved Grafana pllots to show USS instead of PSS. It is clearly private memory of the internal-dpl-ccdb-backend that goes OOM. Any progress?

  • No progress yet understanding the actual problem. The suspicion that it is leaking cached objects is false, since they would stay in SHM not private memory.




High priority framework topics:

• See YETS issues



Other framework tickets:

• Opened a PR to suppress cpu_usage_fraction metrics for input proxies. But proxy detection is not yet optimal.

• TOF problem with receiving condition in tof-compressor: https://alice.its.cern.ch/jira/browse/O2-3681
• Grafana metrics: Might want to introduce additional rate metrics that subtract the header overhead to have the pure payload: low priority.
• Backpressure reporting when there is only 1 input channel: no progress: https://alice.its.cern.ch/jira/browse/O2-4237
• Stop entire workflow if one process segfaults / exits unexpectedly. Tested again in January, still not working despite some fixes. https://alice.its.cern.ch/jira/browse/O2-2710
• https://alice.its.cern.ch/jira/browse/O2-1900 : FIX in PR, but has side effects which must also be fixed.
• https://alice.its.cern.ch/jira/browse/O2-2213 : Cannot override debug severity for tpc-tracker
• https://alice.its.cern.ch/jira/browse/O2-2209 : Improve DebugGUI information
• https://alice.its.cern.ch/jira/browse/O2-2140 : Better error message (or a message at all) when input missing
• https://alice.its.cern.ch/jira/browse/O2-2361 : Problem with 2 devices of the same name
• https://alice.its.cern.ch/jira/browse/O2-2300 : Usage of valgrind in external terminal: The testcase is currently causing a segfault, which is an unrelated problem and must be fixed first. Reproduced and investigated by Giulio.
• Found a reproducible crash (while fixing the memory leak) in the TOF compressed-decoder at workflow termination, if the wrong topology is running. Not critical, since it is only at the termination, and the fix of the topology avoids it in any case. But we should still understand and fix the crash itself. A reproducer is available.
• Support in DPL GUI to send individual START and STOP commands.
• Problem I mentioned last time with non-critical QC tasks and DPL CCDB fetcher is real. Will need some extra work to solve it. Otherwise non-critical QC tasks will stall the DPL chain when they fail.
• DPL sending SHM metrics for all devices, not only input proxy: https://alice.its.cern.ch/jira/browse/O2-4234
• Some improvements to ease debugging: https://alice.its.cern.ch/jira/browse/O2-4196 https://alice.its.cern.ch/jira/browse/O2-4195 https://alice.its.cern.ch/jira/browse/O2-4166
• We desperately need to do a cleanup session and go through all these pending DPL tickets with a higher priority, and finally try to clean up the backlog.



Global calibration topics:

• TPC IDC and SAC workflow issues to be reevaluated with new O2 at restart of data taking. Cannot reproduce the problems any more.



Sync processing

• Proposal to parse InfoLogger message and alert automatically: https://alice.its.cern.ch/jira/browse/R3C-992

• Demoted some InfoLogger messages for missing data from CRORC detectors from alarm to warning, since in low-IR run the data can be missing.




Async reconstruction

• Remaining oscilation problem: GPUs get sometimes stalled for a long time up to 2 minutes.
  • Checking 2 things: does the situation get better without GPU monitoring? --> Inconclusive
  • We can use increased GPU processes priority as a mitigation, but doesn't fully fix the issue.
• ḾI100 GPU stuck problem will only be addressed after AMD has fixed the operation with the latest official ROCm stack.




EPN major topics:

• Fast movement of nodes between async / online without EPN expert intervention.
  • 2 goals I would like to set for the final solution:
    • It should not be needed to stop the SLURM schedulers when moving nodes, there should be no limitation for ongoing runs at P2 and ongoing async jobs.
    • We must not lose which nodes are marked as bad while moving.
• Interface to change SHM memory sizes when no run is ongoing. Otherwise we cannot tune the workflow for both Pb-Pb and pp: https://alice.its.cern.ch/jira/browse/EPN-250
  • Lubos to provide interface to querry current EPN SHM settings - ETA July 2023, Status?
• Improve DataDistribution file replay performance, currently cannot do faster than 0.8 Hz, cannot test MI100 EPN in Pb-Pb at nominal rate, and cannot test pp workflow for 100 EPNs in FST since DD injects TFs too slowly. https://alice.its.cern.ch/jira/browse/EPN-244 NO ETA
• DataDistribution distributes data round-robin in absense of backpressure, but it would be better to do it based on buffer utilization, and give more data to MI100 nodes. Now, we are driving the MI50 nodes at 100% capacity with backpressure, and then only backpressured TFs go on MI100 nodes. This increases the memory pressure on the MI50 nodes, which is anyway a critical point. https://alice.its.cern.ch/jira/browse/EPN-397
• TfBuilders should stop in ERROR when they lose connection.

• AMD ROCm 5.5/5.6 (our current stack) does not support ALMA 8.9. So we can only bump to 8.8. Asked AMD how long they will keep supporting 8.8. If they drop it with ROCm 6.1, doesn't make sense for us to bump...




Other EPN topics:

• Check NUMA balancing after SHM allocation, sometimes nodes are unbalanced and slow: https://alice.its.cern.ch/jira/browse/EPN-245
• Fix problem with SetProperties string > 1024/1536 bytes: https://alice.its.cern.ch/jira/browse/EPN-134 and https://github.com/FairRootGroup/DDS/issues/440
• After software installation, check whether it succeeded on all online nodes (https://alice.its.cern.ch/jira/browse/EPN-155) and consolidate software deployment scripts in general.
• Improve InfoLogger messages when environment creation fails due to too few EPNs / calib nodes available, ideally report a proper error directly in the ECS GUI: https://alice.its.cern.ch/jira/browse/EPN-65
• Create user for epn2eos experts for debugging: https://alice.its.cern.ch/jira/browse/EPN-383
• EPNs sometimes get in a bad state, with CPU stuck, probably due to AMD driver. To be investigated and reported to AMD.



Raw decoding checks:

• Add additional check on DPL level, to make sure firstOrbit received from all detectors is identical, when creating the TimeFrame first orbit.



Full system test issues:

Topology generation:

• Should test to deploy topology with DPL driver, to have the remote GUI available.

  • DPL driver needs to implement FMQ state machine. Postponed until YETS issues solved.



QC / Monitoring / InfoLogger updates:

• TPC has opened first PR for monitoring of cluster rejection in QC. Trending for TPC CTFs is work in progress. Ole will join from our side, and plan is to extend this to all detectors, and to include also trending for raw data sizes.



AliECS related topics:

• Extra env var field still not multi-line by default.



GPU ROCm / compiler topics:

• Found new HIP internal compiler error when compiling without optimization: -O0 make the compilation fail with unsupported LLVM intrinsic. Reported to AMD.
• Found a new miscompilation with -ffast-math enabled in looper folllowing, for now disabled -ffast-math.
• Must create new minimal reproducer for compile error when we enable LOG(...) functionality in the HIP code. Check whether this is a bug in our code or in ROCm. Lubos will work on this.
• Found another compiler problem with template treatment found by Ruben. Have a workaround for now. Need to create a minimal reproducer and file a bug report.
• Debugging the calibration, debug output triggered another internal compiler error in HIP compiler. No problem for now since it happened only with temporary debug code. But should still report it to AMD to fix it.
• Checked AMD ROCm 6.0.2 on both MI50 and MI100. Not stable on both of them, was crashing after a while, ~30 minutes on MI50 nodes. Also saw 3%-4% performance degradation on MI50 compared to ROCm 5.5/5.6. Reported this back to AMD.

  • Old ROCm seems stable with O2/dev, so seems to be indeed a regression in ROCm 6.0.2.

  • On top of that, did a bit of debugging, and the majority of the crashes on the MI100 are due to the known synchronization bug we had on the MI100 beginning of last year, which suddenly disappeared in a new ROCm version. Apparently it was never really fixed, just the race condition didn't occur, and now it is back.

  • On top of that, also MI50 crashes, which is not affected by this bug, so there are at least 2 independent bugs in ROCm 6.0 that make our code fail.




TPC GPU Processing

• Bug in TPC QC with MC embedding, TPC QC does not respect sourceID of MC labels, so confuses tracks of signal and of background events.
• New problem with bogus values in TPC fast transformation map still pending. Sergey is investigating, but waiting for input from Alex.
• Status of cluster error parameterizations
  • Started implementing the usage of new cluster errors / occupancy map in the Refit. Ruben adjusted all the workflows to receive the map.
    • Still lacks on-the-fly creation of the map when missing, and creation of the map in the shared-map-creator when tpc-tracking is not in the workflow. Also, all workflows doing TPC cluster errors must parse the TPC configKeyValues for the cluster errors.

  • No progress yet on newly requested debug streamers.

  • Need to port all of this to  stable-async branch, but again the latest changes do not apply cleanly since stable-async is too old.

• TPC processing performance regression: Currently we need 43% more time than in last year's Pb-Pb, i.e. we are too slow for Pb-Pb this year. This must be fixed!
  • Bisected regressions down to the commits:

    • 18.9.2023 IFC Errors + related 2.48%
      • This comes from multiple commits adding features to the error estimation step by step, none of them causing an increase above 0.5% on its own. This slowdown is not recoverable.

    • 24.10.2023: Revert "MatLUT: faster phi-sector determination; reduction of divisions (#12030)"    3.80%
      • This is a weird behavior in the AMD compiler, triggered by the combination of the revert of this commit, another commit that was added in the meantime, and compile flags. I should be able to find a workaround for this.

    • 30.1.2024: Dead channel map + V-Shape distortion correction    15.77%
      • Dead channel map usage makes 0.8%, which is not recoverable.
      • the remaining 15% come from the V-Shape correction changes in the TPCFastTransform class.

    • 4.3.2024: fix inverse for M-Shape distortions    6.26%
      • Again, changes to the TPCFastTransform class cause the regression.

    • 5.3.2024: 8.90%
      • 0.34% is from using qMax in the error estimation
      • 0.1% from improvements to dEdx computation

      • 1% from building the average of 1/sqrt(qmax)

      • The rest comes from fixes in the tracking code, where cluster to track association got broken, and cuts were applied incorrectly. These 7.5% will not be recoverable.

  • Then, found that some compile flags (fast-math, O2) are overridden by the O2 CMake, and not passed to the GPU compiler, which caused a performance regression compared to the standalone benchmark. This is fixed, but still ~2% performance difference. Checking where this comes from.
  • WIth standalone benchmark and optimized GPU compiler flags, checked performance of TPCFastTransform:

    • O2/dev:
      • Total time: 4.695s, Track Fit Time 1.147s, Seeding Time 1.241s
    • O2/dev with commit from 4.3. reverted:
      • Total time 4.351s, Track Fit Time 1.089, Seeding Time 1.008s
    • For reference: before introduction of the V-Shape map:
      • Total time 3.8421s (didn't measure individual times)
    • O2/dev with scaling factors hard-coded to 0 (essentially using one single transformation map without any scaling):
      • Total time 3.093 Track Fit Time 0.682s Seeding Time 0.429s
    • In summary, having the 3 maps in the code (even if the scaling factor is 0 and the V-Shape map is not used) compared to using one single map, increases the total TPC reconstruction time by > 50%, the track fit time by 100% and the seeding time by 200% on the GPU. As is, the map access on the GPU is extremely inefficient.
  • Proposed 3 ideas to speed up the map access:
    1. We merge the maps on-the-fly to one combined map, and query only one map.
    2. We could add plenty of #ifdef in the code, to make sure that for online purposes all the code for the non-static map is not seen.
    3. We could try to optimize the code to make it easier for the compiler.
• Discussed with Jens in the SCD meeting to schedule a dedicated meeting for this, but no time slot yet.




General GPU Processing

• Started work to make O2 propagator easily usable in ITS tracking, which is not part of the GPU reconstruction library:
  • All GPU framework / common code changes needed for deterministic ITS tracking are merged.
  • Used Giulio's workaround to update the CMAKE flags for lower-case build types.
  • All CUDA code for the external propagator usage have been ported to HIP, confirmed to work by Matteo.-

• Porting CUDA features to HIP:

  • RTC compilation now fully working with HIP. Unfortunately, performance benefit is only 2% compared to 5% with CUDA. Not clear why. Actually I had expercted a larger improvement, since the AMD compiler / hardware seems to suffer more from complicated control flow than NVIDIA, and the constexpr optimization should reduce the control flow.
  • Per-kernel compilation still not available with HIP

• GPU code now compiles with C++20

• Can bump to GCC13 from GPU side - tested locally. Problem is now with flatbuffers / onnxruntime. To be discussed in WP3 / WP4/14 meetings.

• Can not bump LLVM/clang beyond 15 due to a bug in their OpenCL code. Verified that it is still broken in LLVM 18.1.

  • Filed a bug report, they fixed one problem but my reproducer still fails with internal compiler error.

• Fixed GPU compilation for Run2 data / with AliRoot.


11:20 → 11:25 TRD Tracking

Speaker: Ole Schmidt (CERN)

11:25 → 11:30 TPC ML Clustering

Speaker: Christian Sonnabend (CERN, Heidelberg University (DE))

11:30 → 11:35 ITS Tracking

Speaker: Matteo Concas (CERN)

• ITS tracking (GPU): unify usage of vertexer+tracker into a single interface, shared between its-reco-workflow and gpu-reco-workflow
• Now: migrating ITS GPU vertexer:
  • To use the externally-provided GPU allocator (this might also end up in better memory usage thanks to the possibility of allocating different-sized buffers at each set of rofs)
  • Check 1:1 consistency in deterministic mode
  • Make it default in GPU reco (not used currently since the priority was to get 100% consistency in the tracker)

11:35 → 11:55 TPC Track Model Decoding on GPU

Speaker: Gabriele Cimador (Universita e INFN Trieste (IT))

New strategy

• Divide computation of unattached kernels in sectors
• Transfer immediately result

Results on Nvidia 2080

Mean deco timings

• GPU improved: 161.94 ms (last week: 171.77 ms)
• GPU basic: 235.32 ms
• Original: 608.89 ms

On EPN:

New strategy gives same/worst results than this strategy:

Mean deco time on 5.3*10^7 clusters dataset

• New strategy: 215 ms
• Simpler strategy: 205 ms

Mean deco time on 2.7*10^8 clusters dataset

• New strategy: 1.197 ms
• Simpler strategy: 1.186 ms

Mean deco time on 5.3*10^7 clusters dataset on Nvidia machine

• New strategy: 161 ms
• Simpler strategy: 200 ms



Currently tuning number of streams / block and grid size on EPN
