Alice Weekly Meeting: Software for Hardware Accelerators / PDP-SRC - MINUTES ONLY

Wednesday Jan 29, 2025, 10:00 AM → 11:30 AM Europe/Zurich

10:00 AM → 10:20 AM Discussion

Speakers: David Rohr (CERN), Giulio Eulisse (CERN)

10:20 AM → 10:25 AM Following up JIRA tickets

Speaker: Ernst Hellbar (CERN)

10:25 AM → 10:30 AM TPC ML Clustering

Speaker: Christian Sonnabend (CERN, Heidelberg University (DE))

New developments:

• Added local occupancy estimator (this was one request by GSI in the group meeting):
  vector<float> loc_occ(all(pad_time_bins), 0);
  for every pad_time_bin in tpc_sector{
  for pad_time_bin_2 in [time(pad_time_bin) - 20, time(pad_time_bin) + 20] and all_pads_in_ROC(pad_time_bin){
  loc_occ[pad_time_bin] += (int)(pad_time_bin_2 > 0);
  }
  loc_occ[pad_time_bin] /= (all_pads_in_ROC(pad_time_bin) * 41);
  }
• Distortion simulation working now: full-system-test, distortion type 2 + slow-realisitic-full-sim + runnumber=311000
• Got ITS-TPC matching + QC to work using the reco_NOGPU.log (WORKFLOWMODE="print")
• Simulated different IR's and collision systems now (PbPb: 50kHz, 30kHz, 15kHz; pp: 1500kHz, 1000kHz, 500kHz)
• Created dedicated dataset with loopers: 1 Ev. Pb-Pb 500kHz +  lowneut=true = many loopers at high time-bins
• Created dedicated simulation for overlap training data: 5 Ev. Pb-Pb 200 kHz should give a high local occupancy and a lot of overlapping tracks (to be seen if it is locally realisitic)



Performed investigation on spacecharge distorted data.

• Tested NN's trained on not-spacecharge-distorted data to see if they are good enough or need retraining.
• Tested different input sizes and (NN classifciation + NN regression) vs. (NN classification + GPU CF regression) vs. (pure GPU CF regression)
• Overall results:
  • NN classification + NN regression:
    • Regression does not work (well), bands are significantly broader or look like noise. Needs retraining. Was basically expected.
    • When applying all corrections, charge offset of native clusterizer does not appear anymore (investigating)
  • NN classification + GPU CF:
    • Similar effects as in non-distorted data: ~10-20% reduction of clusters. Bands look virtually identical for all variables (CoG pad and time, sigma, etc.) between both algorithms -> So classification seems to be somewhat robust to SC distortion



Plan ahead

• Retrain NN's with SC-distorted data and perform QA again
• Streamline everything more. Currently, many manual steps -> focus on automatization

10:30 AM → 10:35 AM ITS Tracking

Speaker: Matteo Concas (CERN)

10:35 AM → 10:45 AM TPC Track Model Decoding on GPU

Speaker: Gabriele Cimador (Universita e INFN Trieste (IT))

GPU param optimisation

Setup

Measured on Alma 9.4, ROCm 6.3.1, MI50 GPU

Executed grid search for the following kernels:

• MergerTrackFit
• MergerFollowLoopers
• MergerSliceRefit
• MMergerCollect
• CompressionKernels_step0attached
• CompressionKernels_step1unattached


These are the longest single stream kernels. Parameters are independent, so easier to optimise. Custom search space for every kernel (for some can't have large block sizes).

Each mean time is normalised to the mean time of the current (block_size, grid_size) configuration. So < 1 mean a better configuration, > 1 means worse and = 1 equal perfomance as current.

MergerTrackFit

Executed two times (Merger 1 and Merger 2)

pp

Merger 1

• Low IR same performance as normal configuration (grid size dependent on number of tracks)
• High IR same as low IR, except for (64,240) where it also has the same performance as normal

Merger 2

• Low and High IR sync benefits from bigger grid sizes
• High IR async is 34% faster with higher grid sizes than current configuration for async

PbPb

Merger 1

• Larger grid sizes almost reaches current configuration (grid_size * block_size >= n_tracks)

Merger 2

• Low IR can be 10% faster with bigger grid sizes
• High IR is 40% faster with bigger grid sizes

MergerSliceRefit

Kernel is executed 36 times (once per TPC sector).

• pp low IR benefits from lower block sizes
• pp high IR benefits from larger grid and block sizes
• PbPb low IR better with lower block sizes
• PbPb high IR better with larger grid and block sizes

MergerCollect

pp

Must retake some measurments due to some unkown problems. Overall best performance given by (64, 960), while current configuration is (512,60).

PbPb

Roughly same as pp

MergerFollowLoopers

Best configuration uses 900 or 960 as grid size. Current configuration is (256,200).

Compression kernels

Step 0 attached clusters

No significant improvements when changing grid and block sizes.

Step 1 unattached clusters

For High IR, (192,180) shows better performances compared to current configuration (512,120).

Grid search script

Since these kernels are not executed concurrently, their parameters are independent. Hence, a python script to perform multiple grid searches at once has been created:

1. A custom grid search space is defined for each kernel
2. At each iteration, take a new space point, i.e. (block_size,grid_size), from each search space
   1. Modify (automatically) the code, plugging each new configuration into the correspondent kernel call in O2
   2. Compile
   3. Execute and measure kernels timings
   4. Iterate until the largest search space is exhausted. Skip new point sampling if search space has been completely explored.

Pros: Multiple grid searches possible per single run

Cons: Works effectively only with non concurrent kernels

Next things to do

• Try to perform grid search on long kernels with other concurrent kernels
• Determine a way to asses what configuration is the best after grid search (instead of just looking at the heatmaps)
• Create a set of optimum parameters based on beamtype and IR
• Explore best parameters with other IRs
• Explore if best parameters change for different datasets with same beamtype and IR

10:45 AM → 10:55 AM Efficient Data Structures

Speaker: Dr Oliver Gregor Rietmann (CERN)
